Sealed CARB-Type Toroidal Roller Bearings

Sealed toroidal roller bearings combine self-alignment and internal axial-displacement capability with protection against dirt, moisture and lubricant loss. They are suitable for non-locating bearing positions in contaminated or maintenance-sensitive equipment.

Availability:

Quantity:



Inquire Add to Basket

Model:
C4916V, C2216, C2316, C4020V, C2222, C4124V, C3130, C3236, C3180MB, C31/500M

Product Overview

Sealed toroidal roller bearings combine self-alignment and internal axial-displacement capability with protection against dirt, moisture and lubricant loss. They are suitable for non-locating bearing positions in contaminated or maintenance-sensitive equipment.

Available models and complete dimensional data are listed in the following parameter table tab.

Models & Dimensions

Bearing Designation	Boundary Dimensions (mm) – d	Boundary Dimensions (mm) – D	Boundary Dimensions (mm) – B	Basic Load Ratings (kN) – C	Basic Load Ratings (kN) – CO	rpm	d2	D1	r1，2 min	S11	Abutment Dimensions (mm) – da min	Abutment Dimensions (mm) – da max	Abutment Dimensions (mm) – Da max	Abutment Dimensions (mm) – ra max	Calculation Factors – K1	Calculation Factors – K2	kg
C6915-2CS5V	75	105	54	204	325	140	83.6	95.5	1	7.1	79.6	83	100	1	0.073	0.154	1.40
C4015-2CS5V	75	115	40	143	193	130	88.5	104	1.1	7.3	81	88	111	1	0.210	0.063	1.40
C5918-2CS5V	90	125	46	224	400	110	102	113	1.1	4.5	96	101	119	1	0.089	0.131	1.75
C4020-2CS5V	100	150	50	310	450	95	114	136	1.5	6.2	107	113	143	1.5	0.145	0.083	2.90
C4120-2CS5V	100	165	65	475	655	90	120	148	2	7.3	111	119	154	2	0.090	0.125	5.20
C4022-2CS5V	110	170	60	415	585	85	128	155	2	7.9	119	127	161	2	0.142	0.083	4.60
C4122-2CS5V	110	180	69	500	710	85	130	160	2	8.2	121	129	169	2	0.086	0.133	6.60
C4024-2CS5V	120	180	60	430	640	80	140	164	2	7.5	129	139	171	2	0.085	0.142	5.10
C4124-2CS5V	120	200	80	710	1000	75	140	176	2	8.2	131	139	189	2	0.126	0.087	9.70
C4026-2CS5V	130	200	69	550	830	70	152	182	2	8.2	139	151	191	2	0.089	0.133	7.50
C4126-2CS5V	130	210	80	750	1100	70	153	190	2	7.5	141	152	199	2	0.090	0.126	10.5
C4028-2CS5V	140	210	69	570	900	67	163	193	2	8.7	149	162	201	2	0.133	0.089	7.90
C4128-2CS5V	140	225	85	780	1200	63	167	204	2.1	8.9	152	166	213	2	0.086	0.134	12.5
C4030-2CS5V	150	225	75	585	965	63	175	204	2.1	10.8	161	174	214	2	0.084	0.144	10.0
C4130-2CS5V	150	250	100	1220	1860	60	179	221	2.1	6.4	162	178	238	2	0.103	0.103	20.5
C4032-2CS5V	160	240	80	655	1100	60	188	218	2.1	11.4	170	187	230	2	0.154	0.079	12.0
C4132-2CS5V	160	270	109	1460	2160	53	190	241	2.1	6.7	172	189	258	2	0.101	0.105	26.0
C4034-2CS5V	170	260	90	965	1630	53	201	237	2.1	9	180	199	250	2	0.116	0.097	17.0
C4134-2CS5V	170	280	109	1530	2280	53	200	251	2.1	6.7	182	198	268	2	0.101	0.106	27.0
C4036-2CS5V	180	280	100	1320	2120	53	204	246	2.1	6.4	190	202	270	2	0.103	0.105	23.5
C4136-2CS5V	180	300	118	1760	2700	48	211	265	3	6.4	194	209	286	2.5	0.095	0.110	35.0
C4038-2CS5V	190	290	100	1370	2320	48	221	263	2.1	6.4	200	219	280	2	0.103	0.106	24.5
C4138-2CS5V	190	320	128	2040	3150	45	222	283	3	6.4	204	220	306	2.5	0.094	0.111	43.5
C4040-2CS5V	200	310	109	1630	2650	45	229	280	2.1	6.7	210	227	300	2	0.101	0.108	31.0
C4140-2CS5V	200	340	140	2360	3650	43	237	301	3	7	214	235	326	2.5	0.092	0.112	54.5
