SZ-489, SZ-4130, SZ-4131, SZ-4132
BWK
These assemblies integrate a cylindrical roller clutch with ball bearing support in one compact unit. They transmit torque in one direction and overrun freely in the opposite direction while providing radial support.
Integrated one-way clutch and ball bearing support
Compact structure for space-limited installations
Reliable indexing, backstopping and overrunning operation
Simple installation as a combined assembly
Available in SZ series dimensions
Series: SZ
Suitable for compact transmission systems, printing and packaging machinery, conveyors, starter mechanisms and other equipment requiring one-way torque transmission with radial support.
| Shaft Diameter (mm) | Bearing Designation | d (mm) | D (mm) | C (mm) | C1 (mm) | A (mm) | Dynamic Load Cr (N) | Static Load Cor (N) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 25 | SZ-489 | 25 | 47 | 25 | 11 | 3.5 | 8600 | 5600 | 0.1693 |
| 25 | SZ-4130 | 25 | 47 | 18 | 9.5 | 8600 | 5600 | 0.1191 | |
| 25 | SZ-4131 | 25 | 52 | 15 | 8600 | 5600 | 0.1506 | ||
| 25 | SZ-4132 | 25 | 47 | 15 | 8600 | 5600 | 0.1086 |
Dimensions, load ratings, speeds and weights should be confirmed according to the actual operating conditions.
