22213 EK Double Row Spherical Roller Bearing

22213 EK double-row spherical roller bearing with tapered bore with 65 mm bore, 120 mm OD, 31 mm width. Two rows of barrel-shaped rollers share a spherical outer-ring raceway, accommodating shaft misalignment while carrying high radial loads and axial loads. The EK version has a 1:12 tapered bore. Review shaft fit, loads and working conditions before replacement.

Availability:

Quantity:



Inquire Add to Basket

Model:
22213 EK
Brand:
BWK
Code:
BWK-22213-EK

DESCRIPTION

Product Overview

22213 EK is a double row spherical roller bearing. Two rows of barrel-shaped rollers share a spherical outer-ring raceway, accommodating shaft misalignment while carrying high radial loads and axial loads. The EK version has a 1:12 tapered bore.

Key Features

Self-aligning design tolerates shaft deflection
Double-row rollers for demanding radial loads
1:12 tapered bore for sleeve or tapered-seat mounting

22213ek

Technical Specifications

Model	22213 EK
Product Type	Double Row Spherical Roller Bearing
Bore Diameter	65 mm
Outside Diameter	120 mm
Width	31 mm
Bore Design	Taper 1:12
Structure	Double row, self-aligning
Seal Type	Open
Ring / Roller Material	Chrome steel
Cage Material	Steel
Lubrication	Required

Typical Applications

Heavy industrial conveyors and crushers
Gearboxes and mechanical drives
Mining and bulk material handling machinery

Selection Guidance

For tapered-bore installation, follow the specified drive-up or radial-clearance-reduction procedure; check lubrication and alignment under working loads.
