16325001
BWK
BWK-16325001
16325001 is a crossed roller slewing bearing with a 82 in bore, 95 in outside diameter and 4 in overall assembly height. Alternating roller orientations support radial load, axial load and overturning moment. The gearless configuration requires a separately selected drive.
| Model | 16325001 |
| Product Type | Crossed Roller Slewing Bearing |
| Structure | Single row crossed rollers, without gear |
| Dimension Units | Inch (dimensions shown) |
| Series | XR Series |
| Gear | Without Gear |
| Type | Roller |
| Bearing Type | Standard |
| Inside Diameter Of Inner Ring | 82 in |
| Outside Diameter Of Outer Ring | 95 in |
| Internal Diameter On Inner Ring | 82.063 in |
| External Diameter On Outer Ring | 94.875 in |
| Height Of Overall Bearing Assembly | 4 in |
| Height Of Inner Ring | 3.5 in |
| Height Of Outer Ring | 3.5 in |
| Bolt Circle In Inner Ring | 85 in |
| Bolt Circle In Outer Ring | 93 in |
| Size Holes In Inner Ring | 1.063 in |
| Size Holes In Outer Ring | 1.063 in |
| Number Holes In Inner Ring | 48 |
| Number Holes In Outer Ring | 48 |
| Basic Dynamic Load Rating(Ca) | 407250 lbf |
| Basic Dynamic Load Rating(Cr) | 362100 lbf |
| Moment Load Rating | 1450300 ft-lbf |
| Ring Material Options | 42CrMo or 50Mn; confirm supplied grade when ordering |
| Cage Material | Nylon or 300 Series Stainless Steel |
| Seal Material | NBR |
| RoHS | Compliant |
| Weight | 1660 lbs |
Heavy positioning tables, industrial rotary equipment and handling systems.
Assess radial load, axial load and overturning moment together with speed, duty cycle and mounting stiffness. Confirm bolt circles, hole sizes, seal configuration, material grade and lubrication requirements before ordering. Mount on flat, adequately stiff surfaces and follow the specified bolt-tightening procedure.
