16270001
BWK
BWK-16270001
16270001 is a external gear double row ball slewing bearing with a 84.134 in bore, 102.992 in outside diameter and 7.205 in overall assembly height. Two rows of balls support combined loads and overturning moment. An external ring gear provides a pinion-drive interface.
| Model | 16270001 |
| Product Type | External Gear Double Row Ball Slewing Bearing |
| Structure | Double row ball, eight-point contact, external gear |
| Dimension Units | Inch (dimensions shown) |
| Series | DT Series |
| Gear | External Gear |
| Type | Ball |
| Bearing Type | Standard |
| Inside Diameter Of Inner Ring | 84.134 in |
| Outside Diameter Of Outer Ring | 102.992 in |
| External Diameter On Outer Ring | 99.331 in |
| Height Of Overall Bearing Assembly | 7.205 in |
| Height Of Inner Ring | 6.654 in |
| Height Of Outer Ring | 6.654 in |
| Bolt Circle In Inner Ring | 87.205 in |
| Bolt Circle In Outer Ring | 95.906 in |
| Size Holes In Inner Ring | 1.535 in |
| Size Holes In Outer Ring | 1.299 in |
| Number Holes In Inner Ring | 68 |
| Number Holes In Outer Ring | 64 |
| Pitch Diameter Of Gear | 100.787 in |
| Module | 20 |
| Number Of Gear Teeth | 128 |
| Max Gear Tooth Load Fz | 92060 lbs |
| Moment Load Rating | 3658500 ft-lbf |
| Tooth | FD |
| Ring Material Options | 42CrMo or 50Mn; confirm supplied grade when ordering |
| Ball Material | Chrome Steel |
| Cage Material | Nylon or 300 Series Stainless Steel |
| Seal Material | NBR |
| RoHS | Compliant |
| Weight | 3970 lbs |
| Face Width Of Gear Teeth | 5.709 in |
| Addendum Modification Coefficient Of Gear Teeth | 0.5 |
Heavy rotary platforms, lifting equipment and large industrial handling machinery.
Assess radial load, axial load and overturning moment together with speed, duty cycle and mounting stiffness. Confirm bolt circles, hole sizes, seal configuration, material grade and lubrication requirements before ordering. Mount on flat, adequately stiff surfaces and follow the specified bolt-tightening procedure. Check the gear pitch, tooth count, face width and permissible tooth load against the mating pinion.
