SS3304
BWK
BWK-SS3304
BWK SS3304 uses a 20 mm bore and double-row angular contact arrangement to provide balanced radial and bidirectional axial support in pump and drive assemblies.
| Model | SS3304 |
| Product Type | Stainless Steel Double Row Angular Contact Ball Bearing |
| Bore Diameter | 20 mm |
| Outer Diameter | 52 mm |
| Width / Overall Width | 22.2 mm |
| Structure | Double-row angular contact ball bearing |
| Seal | Open |
| Additional Information | 440C Stainless Steel rings; 440C Stainless Steel balls; Steel Cage |
The 20 × 52 × 22.2 mm design offers a practical balance of compact size, combined-load capacity, corrosion resistance and dependable running accuracy.
Suitable for industrial pumps, compact transmissions, processing equipment, electric-drive assemblies and general machinery requiring a 20 mm shaft fit.
BWK provides reliable bearing solutions for industrial and agricultural applications, supported by stable supply, strict quality control and flexible OEM & ODM services.
