RKS.061.25.1314 External Gear Four Point Contact Slewing Bearing

RKS.061.25.1314 is a external gear four point contact slewing bearing with a 48.386 in bore, 57.008 in outside diameter and 2.677 in overall assembly height. The external ring gear supports driven rotation of a large rotary assembly. Check pinion engagement and supporting-structure stiffness for the application.
Availability:
Quantity:
Inquire Add to Basket

  • RKS.061.25.1314

  • BWK

  • BWK-RKS.061.25.1314

DESCRIPTION

Product Overview

RKS.061.25.1314 is a external gear four point contact slewing bearing with a 48.386 in bore, 57.008 in outside diameter and 2.677 in overall assembly height. The external ring gear supports driven rotation of a large rotary assembly. Check pinion engagement and supporting-structure stiffness for the application.

RKS.061.25.1314

Technical Specifications

Model RKS.061.25.1314
Product Type External Gear Four Point Contact Slewing Bearing
Structure Four-point contact ball arrangement with external gear
Dimension Units Inch (dimensions shown)
Series Medium Size Four-Point Contact
Gear External Gear
Type Ball
Bearing Type Standard
Inside Diameter Of Inner Ring 48.386 in
Outside Diameter Of Outer Ring 57.008 in
Height Of Overall Bearing Assembly 2.677 in
Internal Diameter On Outer Ring 51.87 in
Height Of Inner Ring 2.283 in
Height Of Outer Ring 2.283 in
Internal Diameter On Inner Ring 51.594 in
Bolt Circle In Inner Ring 49.646 in
Bolt Circle In Outer Ring 53.819 in
Size Holes In Inner Ring 0.63 in
Size Holes In Outer Ring 0.63 in
Module 10
Number Holes In Inner Ring 50
Number Holes In Outer Ring 50
Pitch Diameter Of Gear 55.906 in
Permissible Tooth Forces T 10125 lbs
Basic Dynamic Load Rating(Ca) 118350 lbf
Number Of Gear Teeth 142
Max Gear Tooth Load Fz 29250 lbs
Diameter Of Bearing Raceway 51.732 in
Basic Static Load Rating(C0a) 985500 lbf
Ring Material Options 42CrMo or 50Mn or 440C; confirm supplied grade when ordering
Ball Material Chrome Steel
Cage Material Nylon or 300 Series Stainless Steel
Seal Material NBR
RoHS Compliant
Weight 166 kg

Applications

Large driven platforms, handling machinery and industrial turntables.

Selection and Installation

Assess axial load, radial load and overturning moment together with speed, duty cycle and mounting stiffness. Confirm the bolt circles, hole sizes, material grade, seal configuration and lubrication requirements before ordering. Use flat, adequately stiff mounting surfaces and the specified bolt-tightening procedure. Match the gear module or diametral pitch, tooth count and gear face width to the pinion, and check the permissible tooth load.
